ChARGING PROGRAMS

Choose program by pressing the MODE-button.
Adjust parameters according to "CHARGING" (6–8).
Press START/PAUSE button to start the selected program.
The table explains the different Charging Programs:
Battery Size
Program
(Ah)
40–1500Ah
NoRmAl
20–750Ah
40–1500Ah
Ca/Ca
20–750Ah
40–1500Ah
AGm/GEl
20–750Ah
40–1500Ah
AGm PoWER
20–750Ah
40–1500Ah
SuPPly
20–750Ah
12V
Current Battery size Min
20A 40Ah
30A 60Ah
40A 80Ah
50A 100Ah
70A* 100Ah
• Using higher current than recommended may result in batteries not being
completely charged.
•Using lower current than recommended will prolong the charging time.
• The currents are the maximum recommended current for battery charg-
ing. If a parallel consumer is connected then the current setting could be
increased with this current value.
• Some battery manufacturer could recommend different values. Please
check with the manufacturer if uncertain. The main recommendations are
that Gel batteries should be charged in the lower current range, Power
AGM's in the upper range and most other battery types in the mid-range.
*) 70/35A Could only be selected for Supply program
6 • EN
Explanation
Use for WET and MF batteries.
Use for Ca/Ca batteries. Use Ca/Ca-program to maximize charge with
minimum loss of fluid. Including RECOND step. Recond your battery once
per year and after deep discharge to maximise lifetime and capacity.
For AGM and GEL batteries which are recommended to receive lower
voltage charge.
Use for AGM batteries which are recommended to receive higher voltage
charge.
Use as 12V/24V power supply or use for float maintenance charging when
100% capacity of the battery is required. Supply program activates step 7
without time or voltage limitation. Supply program enables the charger to
deliver 70A/12V or 35A/24V for 30 seconds.
Battery size Max Current
100Ah 10A
150Ah
15A
200Ah 20A
- 25A
- 35A*
Risk for short circuiting the battery cables. Connect charger cables
Risk for electrical shock if touching positive and negative terminals
Temp range
-20°C–+50°C
(-4ºF–+122ºF)
-20°C–+50°C
(-4ºF–+122ºF)
-20°C–+50°C
(-4ºF–+122ºF)
-20°C–+50°C
(-4ºF–+122ºF)
-20°C–+50°C
(-4ºF–+122ºF)
24V
Battery size Min Battery size Max
20Ah 50Ah
30Ah 75Ah
40Ah 100Ah
50Ah -
50Ah -
WARNING!
to the charger before connecting the battery
WARNING!
when charging
CONNECT ThE CABLES
If the battery clamps are incorrectly connected, the reverse polarity protec-
tion will ensure that the battery and charger are not damaged.
1. Connect the battery cable, including the temperature sensor, to the
charger
2. Connect the mains cable to the charger
3. Connect the red clamp to the battery´s positive pole.
4. Connect the black clamp to the vehicle chassis remote from the fuel pipe
and the battery.
5. Connect the charger to the wall socket
6. Disconnect the charger from the wall socket before disconnecting the
battery
7. Disconnect the black clamp before the red clamp
–
1
–
+
+
Some vehicles may
have positively
earthed batteries
3. Connect the black
4. Connect the red clamp
7. Disconnect the red
4
3
5
2
clamp to the battery´s
negative pole.
to the vehicle chassis
remote from the fuel
pipe and the battery.
clamp before the black
clamp.
