<AUTOMATIC PROCEDURE>
ASSISTED PROCEDURE
NEXT MENU
Gas avail X:XX lb
Type in the vacuum time or confirm the previous value. To simply confirm, press ENTER. To
type in, use keys 0 to 9.
<VACUUM
FILLING
After vacuum time has been confirmed, the "Filling x: xx lb" message will flash. Set the quantity
of refrigerant to be charged, as explained below:
1. Set the quantity of refrigerant required for the A/C system to be charged. For example, for 1
lb 7 oz., press key 1, key 0 and key 7, "Charging 1:07 lb". After setting the quantity, confirm by
pressing the ENTER key.
VACUUM 20 MIN
<FILLING X:XX lb>
In most cases, the quantity of refrigerant being charged into the A/C system is given on
a data plate inside the engine compartment of the vehicle. If you do not know the
correct quantity, consult the relevant manuals.
2. The DATABASE BASIC (DBB) may be used if installed. Press the ↓ key. The following will
appear on the display
Find the relevant vehicle code on the "table" provided. Use the numerical keypad to enter the
code. Then press the ENTER key to confirm. The following will appear on the display:
where "w:yz" refers to the amount of refrigerant for the vehicle selected. The machine
is now ready to enter the correct quantity of refrigerant. Confirm by pressing the
ENTER key. Please contact your retailer if you wish to install the DATABASE BASIC
(DBB).
3. The DATABASE ADVANCED (DBA) may be used if installed: Press the ↓ key, the following
will appear on the display
INSTRUCTIONS MANUAL
XX MIN>
X:XX lb
2
1 0 7 ENTER
INSERT CODE
CAR MODEL
Press ENTER to quit
VACUUM
<FILLING
<VACUUM
FILLING
ENTER
<VACUUM
FILLING
0
Open high and low
pressure, then
press START
...
20 MIN
w:yzlb>
-10-
XX MIN>
X:XX lb
20 MIN>
X:XX lb
