IN S TA L L AT I O N
Completion
Install the grille assembly and check for proper fit. Recon-
nect the network cable. Refer to page 6. Attach the network
cable to the grille using the cable ties provided.
Reinstall the drain pan and verify it is in the proper position.
Install the kickplate using the screws to attach it to the
brackets on the inside of each roller base. Refer to the illus-
tration below. The kickplate must be removable for service.
The floor cannot interfere with removal.
Install the leg covers.
For initial start up, touch and hold
external touch display, located on the grille.
Kickplate installation
14 | Sub-Zero Customer Care 800.222.7820
POWER on either
WATER FILTER B YPASS
If the water filtration system will not be used, it can be
bypassed by removing the water filter.
To Remove the Water Filter:
To access the water filter, rotate the bottom of the grille
1
upward.
To remove the filter, rotate counterclockwise one-quarter
2
turn, then pull out. Refer to the illustration below.
WATER FILTER
Water filter removal
