AXIS Video Server Rack Installation Guide

Axis Rack Mounted Video Server Solution

This installation guide describes the hardware installation of the AXIS 291 1U Video Server Rack,
which can hold up to 3 Axis blade video servers. To install the Axis video server on the network,
please see the video server's own installation guide.

Hardware Inventory

Please contact your dealer if anything is missing or damaged.
Qty Item
1 Video server rack
2 Cover plates
1 AC power cord
1 Warranty Document
1 Mounting kit

Power cord plug variants

Country Europe
Power
cord plug
Mounting kit
Please contact your dealer if anything is missing or damaged.
Qty Item
4 Rubber foot
1 Mounting bracket (side)
1 Mounting bracket (side)
8 M3x8 screw (recessed)
4 M6x20 screw
3 Terminal connector
block
Models/variants/notes
AXIS 291 1U Video Server Rack
Front panel cover 1U
• Europe
• UK
• US, Canada, Japan
• Australia
See separate inventory below
UK US,
Canada,
Japan
Models/variants/notes
For placement on flat surfaces
Left
Right
For attachment of side brackets
For mounting AXIS Video Server
Rack in equipment rack
12-pin, green
• Switzerland
• Denmark
• South korea
Australia Switzerland
Note:
The 2 mounting brackets included
in the mounting kit are slightly
different. See the label on each
bracket.
Page 3
Denmark South
Korea
