INSTALLATION INSTRUCTIONS
The EZ Pro™ can be mounted indoors or outdoors. Find a location near a 120V wiring source
(230/240V for 8678, 8682, 8686, 8690 and 8694 models). Install the EZ Pro™ near eye level
if possible. Use the supplied template to mark and
pre-drill pilot holes in the wall. The middle two hole guides in the EZ Pro™ are vertically
aligned for mounting the controller to a stud. (See Template) Insert screws through the holes
in the case and screw each into the corresponding pilot hole in the wall.
NOTE: The front panel can be removed to aid in installation by removing the ribbon
connector from the interconnect board and pulling the front panel off its hinges.
Wiring the Transformer
120 VAC in United States, Canada and Mexico; 230 VAC in Europe and 240 VAC in Australia
NOTE: Refer to and follow local codes if different from these instructions.
CAUTION Disconnect 110V (230/240V for 8678, 8682, 8686, 8690 and 8694 models) power
source before wiring transformer. Complete all wiring and installation before
connecting the transformer to power source. This will avoid accidental shorting
which could damage the controller.
Power supply cables and cords used for connections are to be a minimum of ordinary duty or
greater duty. Live supply wires should be attached together adjacent to the terminal block.
Low voltage output cables should be enclosed in conduit affixed to the controller with a
suitable adapter. Remove the two screws and lift out the transformer cover to provide access
to the internal transformer, bring 120V (or 230/240 for 8678, 8682, 8686, 8690 and 8694)
wires up through 1/2" conduit hole in the bottom of the case. (For field connection, AC wires
must have an insulation rated at 75°C minimum). Conduit should be secured to the case
(follow local codes).
