Getting Started

Concept

The Strand 200 series console is a mid-level preset lighting desk that is available in two sizes: A 12/24 channel
version and a 24/48 channel version. The 12/24 channel version can either control 24 channels in 1 scene or 12
channels in 2 scenes with the ability to expand scenes with the Hold feature. The 24/48 channel version can
either control 48 channels in 1 scene or 24 channels in 2 scenes with the ability to expand scenes with the Hold
feature.
Both versions of the console patch a single universe of DMX-512 and can contain up to 24 effects (99 steps) -
(6 effects x 4 pages), A submaster can be recorder for every fader and advanced features such as Audio/MIDI
are available.

Ordering Information

Catalog # 64312 – 200 series 12/24 console 120 volt
Catalog # 64313 – 200 series 12/24 console 230/240 volt
Catalog # 64320 – 200 series 24/48 console 120 volt
Catalog # 64321 – 200 series 24/48 console 230/240 volt
Catalog # 64315 – Dust Cover 200 12/24
Catalog # 64325 – Dust Cover 200 24/48
Catalog #64326 – Flash Memory Card
Catalog #64327 – Video Display Card
Mechanical & Environmental Data
Weight: 12/24 – 6.9 kg unpacked 9.5 kg packed
24/48 – 9.5 kg unpacked 12.5 kg packed
Finish: Blue powder coat epoxy paint
Construction: Rigid folded sheet steel
Temperature: 0 – 35°C
Humidity Range: 0-90% non-condensing
Ingress Protection: IP20

Standards Compliance

All units are CE marked. 120 volt consoles include UL, cUL power supplies.

Unpack Console

Unpack the console from the packaging and check that the following components are contained within. If any
parts are missing, or damaged, please contact the carrier and the nearest Strand Lighting office.
List of Parts for North America...
(1) 200 series console
(1) Power cable with UL power supply cable with US 2 pin connector
(1) Manual
List of Parts for Europe and Asia...
(1) 200 series console
(1) Power cable with cUL power supply cable with
(1) UK 2 pin connector and EU 3 pin connector
(1) Manual
