7.8.- AUTO SEND MESSAGE SETTING:

● Turn ON the transceiver.
● The status led indicator will blink with red color.
● Press and hold the [PTT] of any transceiver with DTMF function.
(Besides the transceiver installed with the ATX-3000A).
● Press [#] [#] [6] [1] +
● Press [#] [#] [6] [1] + [0] to disable the repeat message.

7.9.- AUTO SEND MESSAGE TESTING:

● Press [#] [#] [6] [2] for testing your last setup.
(* The status led indicator will blink in blue color every 10 seconds).
If you press ##611 before, this function will repeat your message twice within 20 seconds.
If you press ##612 before, this function will repeat your message twice within 40 seconds.
If you press ##613 before, this function will repeat your message twice within 60 seconds.
If you press ##614 before, this function will repeat your message twice within 80 seconds.

8.- OPTIONAL ACCESSORIES:

You have multiples optional control cables for repeater function to connect transceivers of brands
Dynascan, Wouxun, Motorola, Kenwood, Icom, Alinco, Vertex Standard, Yaesu, Midlan, Baofeng,
etc. To choose the right cable, consult your distributor or salesperson.
Optionally also has USB power supplies for different countries.

9.- TECHNICAL SPECIFICATIONS:

Power supply:
Charging and external power supply:
Current:
DTMF remote control protection:
Battery life in standby mode:
Recording message time:
Indicators:
Dimensions:
Weight (gr):
[1] Repeat message once each 15 minutes.
[2] Repeat message once each 30 minutes.
[3] Repeat message once each 45 minutes.
[4] Repeat message once each 60 minutes.
(* The status led indicator will blink in blue color each 10 seconds).
Build-in 3.7 V/900 mAh Li-Ion battery.
5 - 24 VDC.
4 mA in standby mode and 20-30 mAh in working mode.
User defines 4 digit password protections.
180 hours (approx.).
Up to 180 seconds.
Status led and external power supply input led.
110 x 80 x 25 mm.
84 gr (without accessories).
English - 13 -
