SKM 100 hand-held transmitter

Sound inlet basket
Colour-coded identification ring for microphone modules
green: MD 835 microphone module
(cardioid dynamic microphone)
blue: MD 845 microphone module
(super-cardioid dynamic microphone)
red: ME 865 microphone module
(super-cardioid condenser microphone)
Body of hand-held transmitter
Battery compartment
Display section
Turnable protective cap for operating controls (shown removed)
The following operating controls become accessible in turn by turning
the protective cap
SET button
button (DOWN)
button (UP)
µ
MUTE switch
¸
ON/OFF button
¹
Red LED for operation and battery status indication
:
