17.1 Harness Routing

J10 and J11
Connection
4
3
M1 Reel Motor
96
J14 CAN Diagnostic Connector
R1 Hand Throttle Potentiometer
Reel Motor
2
6
J12 and 13
Traction Motor
Connection
SW1Reel Switch
F230 Amp Fuse
R2 Rotary Switch
J6 and J7
Reel Motor
Controller
Connection
J22 and J24
Engine
GC2
Shutdown
J23 48V
Power
J15 Light Kit
6
5
M2 Traction Motor
SW2 Ignition
Switch
J1 and J2
Controller
Connection
J8 and J9
Traction Motor
Controller
Connection
1
GC1
8
7
