Display Angle Adjustment; Adjust The Angle Of The Display - Eclipse AVN4400 Manual Del Propietário

Introduction
5

Display angle adjustment

Adjust the angle of the display

The screen viewing angle can be adjusted to any of 6 tilt positions when
the light from outside the vehicle makes viewing difficult.
Hold down
1
second.
• Each press changes the degree of the slope in
stages. The degree of the slope changes by 5
each time, up to a maximum of 30
• Be careful not to pinch your hands or other objects when adjusting the angle of the
display. This could cause an injury or damage to the display.
• When the display is in the TILT status, do not insert a disc or anything else into the
gap at the top. This may damage the main unit and the disc.
• Observe the following cautions when adjusting the angle of the display.
<Automatic transmission vehicle>
When setting the tilt, make sure there is no interference generated from your hand or
other obstructions setting when either in Park, Reverse or Neutral. (If there is
interference when in Drive, do not set the tilt.)
<Manual transmission vehicle>
When setting the tilt, make sure there is no interference generated from your hand or
other obstructions when either in 1st, 3rd, 5th or
interference, do not set a tilt position.)
for more than one
°
.
16
°
(Reverse) gear. (If there is
