Implementación MIDI
(*1) See '2. Address Map for Data Transfer' section.
(*2) Control Change of the odd number of channel is transmitted and received
when Channel Link is On.
(*3) Value and switching Track status corresponds as follows.
(1) While VS-1680 stops
Value :
0-31
32-63
Status:
MUTE->MUTE
MUTE->PLAY
PLAY->MUTE
PLAY->PLAY
REC->MUTE
REC->PLAY
SOURCE->MUTE
SOURCE->PLAY
(2) While playback/recording
Value :
0-31
32-63
Status:
MUTE->X
MUTE->PLAY
PLAY->MUTE
PLAY->PLAY
REC->X
REC->X
SOURCE->MUTE
SOURCE->X
(*) Impossible to switch while recording.
(*) X = ignored
Bank select (MSB/LSB)
Switches the effect bank of Preset/User.
VS-1680 never transmits this message.
Status
Second
Third
BnH
00H
mmH
BnH
20H
llH
n = MIDI Channel No. :
0H - 3H ( ch.1 = Effect1 ch.2 = Effect2
ch.3 = Effect3 ch.4 = Effect4 )
mm = upper byte of bank number : 00H
ll = lower byte of bank number :
00H - 04H (0 - 4)
Bank Select | Program Change
MSB | LSB |
00H | 00H | 00H - 63H (0 - 99) | Preset #000 - #099
00H | 01H | 00H - 63H (0 - 99) | Preset #100 - #199
00H | 02H | 00H - 09H (0 -
00H | 03H | 00H - 63H (0 - 99) | User
00H | 04H | 00H - 63H (0 - 99) | User
NRPN(MSB/LSB)
Selects a parameter of the effect to be controlled.
VS-1680 never transmits this message.
Status
Second
Third
BnH
62H
llH
BnH
63H
mmH
n = MIDI Channel No. : 0H - 3H
( ch.1 = Effect1 ch.2 = Effect2 ch.3 = Effect3 ch.4 = Effect4 )
mm = upper byte of the parameter number to be assigned with NRPN : 00H
ll = lower byte of the parameter number to be assigned with NRPN :
Data Entry (MSB/LSB)
Controls effect parameter assigned with NRPN.
VS-1680 never transmits this message.
Status
Second
Third
BnH
06H
mmH
BnH
26H
llH
n = MIDI Channel No. : 0H - 3H
( ch.1 = Effect1 ch.2 = Effect2 ch.3 = Effect3 ch.4 = Effect4 )
mm = upper byte corresponding to the parameter assigned with NRPN
ll = lower byte corresponding to the parameter assigned with NRPN
<Ex>
mmH llH = 40H 00H = -8192
= 7FH 7FH = -1
= 00H 00H = 0
= 3FH 7FH = +8191
Data Increment
Increments the effect parameter selected with NRPN.
VS-1680 never transmits this message.
26
64-95
96-127
MUTE->REC
MUTE->SOURCE
PLAY->REC
PLAY->SOURCE
REC->REC
REC->SOURCE
SOURCE->REC
SOURCE->SOURCE
64-95
96-127
MUTE->X
MUTE->X
PLAY->X
PLAY->X
REC->REC
REC->SOURCE(*)
SOURCE->REC(*) SOURCE->SOURCE
| Patch Number
|
9) | Preset #200 - #209
#000 - #099
#100 - #199
00H - 2EH (0 - 46)
Status
Second
Third
BnH
60H
00H
n = MIDI Channel No.
: 0H - 3H
( ch.1 = Effect1 ch.2 = Effect2 ch.3 = Effect3 ch.4 = Effect4 )
Increment the effect parameter selected with NRPN.
Data Decrement
Decrement the effect parameter selected with NRPN.
VS-1680 never transmits this message.
Status
Second
Third
BnH
61H
00H
n = MIDI Channel No. : 0H - 3H
( ch.1 = Effect1 ch.2 = Effect2 ch.3 = Effect3 ch.4 = Effect4 )
Decrement the effect parameter selected with NRPN.
NRPN and Effect parameters
Algorithm 0 Reverb (EFX1 or EFX3)
+—————————+—————————+—————————————————————————————————————————————+
|
NRPN
| Data
|
|
|
Entry |
|=========+=========+=============================================|
| 00H 00H | mmH llH | EQ SW
|—————————+—————————+—————————————————————————————————————————————|
| 00H 01H | mmH llH | EQ: Low EQ Type
|—————————+—————————+—————————————————————————————————————————————|
| 00H 02H | mmH llH | EQ: Low EQ Gain
|—————————+—————————+—————————————————————————————————————————————|
| 00H 03H | mmH llH | EQ: Low EQ Frequency
|—————————+—————————+—————————————————————————————————————————————|
| 00H 04H | mmH llH | EQ: Low EQ Q
|—————————+—————————+—————————————————————————————————————————————|
| 00H 05H | mmH llH | EQ: Mid EQ Gain
|—————————+—————————+—————————————————————————————————————————————|
| 00H 06H | mmH llH | EQ: Mid EQ Frequency
|
|
|
|—————————+—————————+—————————————————————————————————————————————|
| 00H 07H | mmH llH | EQ: Mid EQ Q
|—————————+—————————+—————————————————————————————————————————————|
| 00H 08H | mmH llH | EQ: High EQ Type
|—————————+—————————+—————————————————————————————————————————————|
| 00H 09H | mmH llH | EQ: High EQ Gain
|—————————+—————————+—————————————————————————————————————————————|
| 00H 0AH | mmH llH | EQ: High EQ Frequency
|
|
|
|—————————+—————————+—————————————————————————————————————————————|
| 00H 0BH | mmH llH | EQ: High EQ Q
|—————————+—————————+—————————————————————————————————————————————|
| 00H 0CH | mmH llH | EQ: Out Level
|—————————+—————————+—————————————————————————————————————————————|
| 00H 0DH | mmH llH | Reverb: Room Size
|—————————+—————————+—————————————————————————————————————————————|
| 00H 0EH | mmH llH | Reverb: Reverb Time
|—————————+—————————+—————————————————————————————————————————————|
| 00H 0FH | mmH llH | Reverb: Pre Delay
|—————————+—————————+—————————————————————————————————————————————|
| 00H 10H | mmH llH | Reverb: Diffusion
|—————————+—————————+—————————————————————————————————————————————|
| 00H 11H | mmH llH | Reverb: Density
|—————————+—————————+—————————————————————————————————————————————|
| 00H 12H | mmH llH | Reverb: Early Reflection Level
|—————————+—————————+—————————————————————————————————————————————|
| 00H 13H | mmH llH | Reverb: LF Damp Frequency
|
|
|
|—————————+—————————+—————————————————————————————————————————————|
| 00H 14H | mmH llH | Reverb: LF Damp Gain
|—————————+—————————+—————————————————————————————————————————————|
| 00H 15H | mmH llH | Reverb: HF Damp Frequency
|
|
|
|—————————+—————————+—————————————————————————————————————————————|
| 00H 16H | mmH llH | Reverb: HF Damp Gain
|—————————+—————————+—————————————————————————————————————————————|
| 00H 17H | mmH llH | Reverb: HI Cut Frequency
|
|
|
|—————————+—————————+—————————————————————————————————————————————|
| 00H 18H | mmH llH | Reverb: Effect Level
|—————————+—————————+—————————————————————————————————————————————|
| 00H 19H | mmH llH | Reverb: Direct Level
|—————————+—————————+—————————————————————————————————————————————|
| 00H 1AH | 00H 00H | (Reserved)
|
:
|
:
|
| 00H 7FH | 00H 00H |
+—————————+—————————+—————————————————————————————————————————————+
Algorithm 1 Delay
+—————————+—————————+—————————————————————————————————————————————+
|
NRPN
| Data
|
|
|
Entry |
|=========+=========+=============================================|
| 00H 00H | mmH llH | Delay SW
|—————————+—————————+—————————————————————————————————————————————|
| 00H 01H | mmH llH | EQ SW
|—————————+—————————+—————————————————————————————————————————————|
|
|
0,1 = Off,On|
0,1 = Shelving, Peaking|
-12,,,12dB|
2,,,200 = 20,,,2000Hz|
3,,,100 = 0.3,,,10.0|
-12,,,12dB|
|
20,,,800 = 200,,,8000Hz|
3,,,100 = 0.3,,,10.0|
0,1 = Shelving, Peaking|
-12,,,12dB|
|
14,,,200 = 1.4,,,20.0kHz|
3,,,100 = 0.3,,,10.0|
0,,,100|
5,,,40m|
1,,,320 = 0.1,,,32.0s|
0,,,200 = 0,,,200ms|
0,,,100|
0,,,100|
0,,,100|
|
5,,,400 = 50,,,4000Hz|
-36,,,0dB|
|
10,,,200 = 1.0,,,20.0kHz|
-36,,,0dB|
|
2,,,200 = 0.2,,,20.0kHz|
-100,,,100|
-100,,,100|
|
|
|
|
|
0,1 = Off,On|
0,1 = Off,On|
