Parts List

Key
1
2
3
4
5
6
7
8
9
10
11*
12*
13
14
15
16
17
18
19
20
21*
22
23
25*
26
27
28
29
30
31
32
33
34
35
36
37
38
39
*
Greenlee / A Textron Company
Part No. Description
52020160 Puller assembly (includes items 2–27)
52020161 Weldment, frame ............................................................................1
52020171 Motor .............................................................................................1
52020174 Sprocket ........................................................................................1
52020173 Washer, thrust ................................................................................2
52020172 Sprocket, driver .............................................................................1
52020175 Pawl ...............................................................................................1
52020176 Guard, chain ..................................................................................1
52020177 Spring, torsion ...............................................................................1
52020178 Screw, 1/4-20 x 1.00 button head .................................................4
Screw, unit .....................................................................................1
Spacer............................................................................................1
90516672 Screw, cap 1/4-20 x .625 button socket head ..............................4
52020181 Screw, #10-32 x 3/8 socket head cap ...........................................1
52020183 Washer, flat #10 x 5/8 OD flat ........................................................1
90531949 Screw, self-tapping #10-16 x 16 x .250 Phillips head ...................7
52023708 Capstan, assembly ........................................................................1
90513797 Ring, retaining .500 Truarc #5100 ex .............................................1
52020199 Chain, roller #40 1/2" pitch (not shown) ........................................1
52021551 Decal ..............................................................................................1
Washer, shim ..................................................................................3
90505794 Screw, 1/4-20 x 1/2 socket head ...................................................1
90521080 Nut, hex, 1/4-20 .............................................................................1
End cap ..........................................................................................1
52024480 Strap, velcro ...................................................................................1
52020200 Box, switch (includes items 28–39) ...............................................1
52020201 Base ..........................................................................................1
52020202 Cover .........................................................................................1
90541243 Bushing, strain relief..................................................................1
52020203 Clamp, hose ..............................................................................2
50310470 Cord unit, electric power (2001) ................................................1
52020204 Bushing .....................................................................................1
90531949 Screw, self-tapping #10-16 x .250 Phillips head ......................6
90522036 Screw, machine #6-32 x .250 round head ................................2
52021068 Breaker, circuit 12 amp .............................................................1
91862639 Nut, 1/2" conduit .......................................................................1
90502507 Screw, #8-32 x 3/8 socket head cap ........................................1
90524349 Hex nut, #8-32 ..........................................................................1
52057551 Capstan service kit (includes items marked with an asterisk)
UT2 Cable Pulling System
45
4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
Qty
