Specifications

General
System
Total lines
System
per frame
575/50I (PAL) 625
480/60I (NTSC) 525
576/50P 625
480/60P 525
1080/48I 1125
1080/50I 1125
1035/60I 1125
1080/60I 1125
720/60P 750
PVM-14L5
CRT: HR Trinitron, SMPTE-C standard
luminescent material
Power: AC100 to 240V, 50/60Hz
Power consumption:
Maximum 120W, 1.2 to 0.6A
(when the optional BKM-150CP
has been installed)
Standard: 110W, 1.1 to 0.5A
(Without optional board, 720/60P
input)
Dimensions (max.):
Approx. 346 × 280 × 424mm
5
(13
(w/h/d)
Mass: Approx. 17kg (37 lb 8 oz)
PVM-20L5
CRT: HR Trinitron, SMPTE-C standard
luminescent material
Power: AC100 to 240V, 50/60Hz
Power consumption:
Maximum 140W, 1.4 to 0.7A
(when the optional BKM-150CP
has been installed)
Standard: 130W, 1.3 to 0.6A
(Without optional board, 720/60P
input)
Dimensions (max.):
Approx. 452 × 414 × 500mm
7
(17
(w/h/d)
Mass: Approx. 31kg (68 lb 5 oz)
Frame
Active lines
rate
per frame
(Hz)
575
483
576
483
1080
1080
1035
1080
720
× 11 × 16
1 3
/ / / inches)
8 8 4
× 16 × 19
3 3
/ / / inches)
8 8 4
Scanning Aspect
format
25 2:1 Interlace 16:9/4:3
30 2:1 Interlace 16:9/4:3
50 Progressive 16:9/4:3
60 Progressive 16:9/4:3
24 2:1 Interlace
25 2:1 Interlace
30 2:1 Interlace
30 2:1 Interlace
60 Progressive
Input/output connectors
Input
LINE A input connector
Y/C input
VIDEO input
AUDIO input
LINE B input connector
VIDEO input
AUDIO input
RGB/Component input connector
RGB input 0.7Vp-p ± 6dB (Sync On Green,
Component input
AUDIO input
Externally synchronized input
Standard
ratio
ITU 601
ITU 601
—
SMPTE 293M
16:9 —
16:9 SMPTE 294M
16:9 BTA S-001B
16:9 SMPTE 274M/BTA S-001B
16:9 SMPTE 296M
4-pin mini-DIN (1)
See the pin assignment
BNC type (1) 1Vp-p ± 6dB
negative synchronization
Pin jack (1) –5dBu 47 kΩ or higher
BNC type (1) 1Vp-p ± 6dB
negative synchronization
Pin jack (1) –5dBu 47 kΩ or higher
BNC type (3)
0.3Vp-p negative sync.)
0.7Vp-p ± 6dB (75% chrominance
standard color bar signal)
Pin jack (1) –5dBu 47 kΩ or higher
BNC type (1) 0.3 to 8Vp-p
± bipolarity ternary or negative
polarity binary
23
