5.
Install Sensors
Outdoor Sensor
Sensor with rear Sensor with bottom
entry wiring entry wiring
6.
Install Enclosure
8.

Low Voltage Wiring

Mix or DHW
Sensor
Tank
Sensor
Boiler Supply
Sensor
Heat Pump Return
Sensor
Outdoor
Sensor
Setpoint Call
DHW Call
from DHW
Tank Aquastat
(optional)
A Watts Water Technologies Company
Sensor mounted onto
2" x 4" electrical box
tekmarNet ® 2 Thermostats
tN2 tN2 tN2 tN2 tN2 tN2
Mix/DHW tN2 tN2 tN2 tN2 tN2 tN2 tN2 tN2 Rc1 Y1 O/B
No Power
Zone 1 Zone 2 Zone 3
Menu Item
House Control 406
Zone 1 Zone 2 Zone 3 Zone 4
Input Power
C Vlv C Vlv C Vlv C Vlv C
Zone Valves
Pipe Sensors
Retaining Clip
7.
Install Cover
tN2 tN2
Zone 4
R
R
C
24 V (ac) Transformer 009
2
Universal
Sensor 082
Sensor Well
tekmarNet ®
tN4 Tank
Expansion to
Expansion
Wiring Centers,
Timers, or
tN4 Boil/Mix
Expansion User Switch
Modulating
Modulating Boiler
Boiler
1
One Stage Boiler
T-T
Two Stage Heat Pump
L
N
© 2014 406_Q - 02/14
