Fault diagnosis

Fault Condition
__________________________________________________________________________________________________________________
E05 Gate neither opens nor closes
__________________________________________________________________________________________________________________
E06 Gate reverses/does not close
_________________________________________________________________________________________________________
E07 Gate reverses/does not close
__________________________________________________________________________________________________________________
E08 Gate neither opens nor closes
__________________________________________________________________________________________________________________
E09 Gate neither opens nor closes
__________________________________________________________________________________________________________________
E10 Teach-in of the light barrier position
__________________________________________________________________________________________________________________
E51 Gate does not open
__________________________________________________________________________________________________________________
E52 Gate neither opens nor closes
__________________________________________________________________________________________________________________
E53 Gate does not close
__________________________________________________________________________________________________________________
E54 Gate does not open
__________________________________________________________________________________________________________________
E55 Gate neither opens nor closes
__________________________________________________________________________________________________________________
E56 Gate does not close
__________________________________________________________________________________________________________________
E5E Gate only closes in the dead-man mode
Fault Condition
__________________________________________________________________________________________________________________
F2 No response
__________________________________________________________________________________________________________________
F3 No response
__________________________________________________________________________________________________________________
F4 No response
__________________________________________________________________________________________________________________
F5 No response
__________________________________________________________________________________________________________________
F6 No response
__________________________________________________________________________________________________________________
F10 Gate stops after the start command
__________________________________________________________________________________________________________________
F19 Gate only closes in the dead-man mode
__________________________________________________________________________________________________________________
F20 Gate only closes in the dead-man mode
__________________________________________________________________________________________________________________
F21 Brief interruption of operation
__________________________________________________________________________________________________________________
F24 No response to the start command
__________________________________________________________________________________________________________________
F27 Gate does not reach end position; gate
neither opens nor closes
__________________________________________________________________________________________________________________
F28 No response to the start command
__________________________________________________________________________________________________________________
F29 Motor rotates in the wrong direction
Gate stops after the start command
Gate stops after reversing
__________________________________________________________________________________________________________________
F30 Gate only closes in the dead-man mode
__________________________________________________________________________________________________________________
F33 Gate stops during opening
__________________________________________________________________________________________________________________
F34 Gate neither opens nor closes
Diagnosis/Remedy
Safety circuit at J3 is interrupted.
Check the slack rope switch; wicket door not closed.
Edge safety device has tripped; check the edge safety device and is
an AK edge safety device keep the programming button in menu
The light barrier has tripped.
The thermo-contact for the drive has tripped; let the drive cool down.
Emergency drive release; unlock the drive again.
No end position taught-in; tech-in the gate end positions in menus
Position of the light barrier in the frame not taught in. Open and close
adjust the light barrier.
Permanent start of the cover button OPEN, button might be jammed,
Cover button STOP has been pressed. Button might be jammed. Cable
been plugged in.
Permanent start of the cover button CLOSE, button might be jammed
Permanent start J1.3 > button OPEN, button might be jammed, check it
External STOP button J1.2 has been pressed or bridge is missing. Check
connecting cable to the external command transmitter.
Permanent start J1.4 > button CLOSE, button might be jammed, check it
Service cycle has expired; have the system serviced.
Diagnosis/Remedy
Fault during the self-test; switch control off/on
Fault during the self-test; switch control off/on
Fault during the self-test; switch control off/on
Fault during the self-test; switch control off/on
Fault during the self-test; switch control off/on
Fault in the control electronics; switch control off/on
Test of the DW edge safety device failed; check the edge safety device.
Test of the light barrier failed; check the light barrier
Runtime limitation of the gate; let the drive cool down for approx. 20 min
No connection with the DES; check both power supply cable and DES
. Springs overstressed. Check the door balance. Adjust the end positions
Drive is blocked. Check the gate's mechanical system,the mains and motor phases.
Fault in the power supply; check the connection with the mains.
Check whether the 24-V consumers are short-circuited.
Mains phases have been transposed: correct the mains phases or re
Gate drive is too fast, the overrun of the drive is too high.
Return of the pulse into the dead-man mode. Edge safety device or light barrier has tripped.
Opening force limitation has been activated. The motor's power-on time has been exceeded.
The opening force limitation has tripped. Gate can only be closed in the dead-man mode.
Rectify the gates sluggishness or blockage. Check the springs. Eliminate the cause of
exceeding the force limitation and open and close the gate thereafter.
The motor's power-on time (menu 49) has been exceeded. Wait a while and let the motor cool down.
cables. In the case of
[35] pressed.
[30] / [31].
the gate completely,
check it.
might not have
.
.
.
.
.
.
.
.
.
.
in menus 33 &34
adjust them.
Subject to modifications
