2. Tubular motor with built-in control unit
2.1 Tubular motor for awnings and rolling shutters with built-in control unit
This automatic opening system consists of a tubular motor with the following features:
• It is provided with a 434.15 MHz super-heterodyne radio receiver.
• It is driven by means of R-CONTROL transmitters.
• It is possible to drive the actuator also by mean of an external push-button (type: Normally Open, each
series or model).
• The programming phase can be effected via radio or by means of an external switch.
2.2 Functioning with external wired switch
Pressing the external wired switch, the control unit has the following functioning logic:
OPENS __ STOPS __ CLOSES __ STOPS __ OPENS ...
2.3 Functioning with transmitters
At each push button pressure, the functioning logic is the following.
CLOSE > CLOSE > CLOSE
STOP > STOP > STOP
OPEN > OPEN > OPEN
2.4 Transmitters programming
Up to 48 different channel can be stored on each central unit. To store the transmitters read carefully theparagraph
"PROGRAMMING OF THE FUNCTIONS BY MEANS OF A TRANSMITTER OF THE R-CONTROL SERIES".
17
