5.5 Checking the Output
Output Voltage Regulation
1. Connect the device to the mains.
2. Press V/A to switch to voltage mode.
3. Adjust to the desired value (from 1 to max. 30 V).
4. Press the OUT button to put the device in output mode.
Output Constant Current Mode
1. Connect the device to the mains.
2. Adjust the voltage to 30 V.
3. Connect the resistance (3 Ω/50 W) between the output terminals.
4. Press V/A to switch to current mode and adjust the various current
values.
5. Press the OUT button to put the device in output mode and check the
displayed current values.
Output Short-Circuit Protection
1. Connect the device to the mains.
2. Adjust the voltage to > 5 V and the current to > 1 A.
3. Press the OUT button to put the device in output mode.
4. Connect the output terminals
USB Charging Function
1. Connect the device to the mains.
2. Adjust the current to > 2.5 A.
3. Press V/A to switch to voltage mode.
4. Press the USB button to activate the USB output.
5. Press the OUT button to put the device in output mode.

5.6 Other Functions

Data Saving
1. Connect the device to the mains.
2. In setting mode, press the STORE/RECALL button to open the
memory banks.
3. Select your memory bank with
4. Press SET to save the set values into the selected memory bank.
V. 03 – 28/10/2016
LABPSHH01
or .
